In the Main Menu, click Setup, Program Links. Double-click on Ez3Di.

Ez3D-i is an imaging product from Vatech. Website: https://vatechamerica.com/products/ez3d-i

If using EzDent-i for 2-D imaging, set up the EzDent-i Bridge. Vatech also offers the Clever One Bridge.

Bridge Setup

Enter the necessary settings to enable this bridge. Only the fields that need edits are displayed below.

• Enabled: Check to enable this bridge.
• Path of file to open: The location of the program executable. Defaults to C:\Program Files (x86)\VATECH\Clever One\Bin\CleverOne.exe.
• Text on button: The description used on the button as it appears in the toolbar. Defaults to Ez3Di.
• Additional Properties: Enter any additional properties to launch this bridge accurately.
  • Enter 0 to use PatientNum, or 1 to use ChartNum: Double-click to determine which identifier is used to launch the patient in the bridge. Usually 0.
• Button Settings: Determine the visual behavior of the bridge button.
  • Hide Button for Clinics: If using clinics, determine which clinics this button should and should not display for.
  • Add a button to these toolbars: Determine which toolbars this button should display under. Defaults to ChartModule.
  • Button Image: (Optional) Import an image to show on the button (must be exactly 22 x 22 pixels).

Click Save to submit changes.

Technical Details

The bridge sends patient data from Open Dental to an XML text file. Example file:

<LinkageParameter>

<Patient LastName="Smith" FirstName="John" ChartNumber="123">

<Birthday>18/12/1972</Birthday>

<Address>123 Main St, Salem, OR</Address>

<ZipCode>97302</ZipCode>

<Phone>(503)363-5432</Phone>

<Mobile>(503)215-3215</Mobile>

<SocialID>123456789</SocialID>

<Gender>Male</Gender>

</Patient>

</LinkageParameter>

The text file is called linkage.xml, and is created in the same folder on the local computer as the EasyDent program is located.

Open Dental then launches Ez3D-i, which picks up the information in the linkage.xml file.

If no file is present, Ez3D-i opens with no patient selected.

If the patient is not recognized by Ez3D-i, a new patient is created in Ez3D-i.
